Model :900 Series
Features :4 Wheel Mechanical Flow Meter
Accuracy : ± 2%
Flow Rate :6 to 40 GPM ( 20 to 151 LPM )
Pressure rating ( PSI ) :50 (3.4 bar )
Resetable cumulative totalizer : 999.9 Gallons / 9,999 Liter
Master totalizer : 999,999.9 Gallons / 9,999,999 Liter
Construction : Aluminium
Large easy to read numbers : Yes
Plexible ports for horizontal or vertical positioning : Yes
360° Positionable Ports : -
Approvals : UL/CSA Listed
20 Calibration Settings : -
Powered by two AA batteries : -
Gallon or liter Registration : Yes
Painted black for instalation on eitherHeavy Duty Standard Duty pumps except FR4210 ;comes with all fitting :
1" Ports :
1-½" Ports : Yes
Gravity-flow strainer straps tank contaminants : -
BSP threads : Yes
SAE threads :
Teflon or nickel coatings increase selection of compatible fluids : Yes
Compatible fluids : Diesel Fuel, gasoline, kerosene, mineral spirits, stoddard solvent and heptane
