FIELD CBR TEST SET ( CBR Lapangan)
ASTM D-4429; According SNI 03-1738-1989
For determining CBR value on place
Consist of :
- Mechanical Jack
Cast alumunium housing, 5 tons cap, hand operated, 2 speeds.
Consist of :
- Mechanical Jack; 5 tons capacity ( 1 pc)
- Swivel head; cast alumunium ( 1 pc)
- Field Penetration Piston
Machine steel, plated, adjustable height
Consist of :
- Penetration Piston
Machine steel, plated, 3 sq.in.cross section area ( 1 pc)
- Extention set ( 1 set)
Machined steel, plated, 5 cm, 10 cm, 20 cm, 30 cm, and 60 cm,
provided with connecting adaptor.
- Reference Beam; steel pipe, 150 cm span ( 1 set)
- Circular Surcharge Weight
Machine steel, plated, 10 " dia, 10 lbs weight ( 1 pc)
- Slotted Surcharge Weight ( 1 pc)
Machine steel, plated, 8 " dia, 10 lbs weight.
- Slotted Surcharge Weight
Machine steel, plated, 8.5 " dia, 20 lbs weight ( 1 pc)
- Proving Ring; 2.000 lbs capacity, Calibrated ( 1 set)
- Proving Ring; 10.000 lbs capacity, Calibrated ( 1 set)
- Dial Indicator; range 30 x 0.01
